12 Poles Electronic Green pcb terminal block connector PA66 Pitch 2.54mm

12 Poles Electronic Green pcb terminal block connector PA66 Pitch 2.54mm

    • 12 Poles Electronic Green pcb terminal block connector PA66 Pitch 2.54mm
    • 12 Poles Electronic Green pcb terminal block connector PA66 Pitch 2.54mm
  • 12 Poles Electronic Green pcb terminal block connector PA66 Pitch 2.54mm

    Product Details:

    Place of Origin: Guangdong China
    Brand Name: SCED
    Certification: CE,UL,CUL,CQC,VDE etc.
    Model Number: TJ254-02

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 Piece/Pieces
    Packaging Details: Standard Master Carton Dimension: 341 x 273 x 198mm; Standard Inner box dimension: 168 x 134 x 47mm.
    Delivery Time: 5-20 days
    Payment Terms: L/C, T/T
    Supply Ability: 1000000 Pole/Poles per Month
    Contact Now
    Detailed Product Description
    Pitch: 2.54mm Color: Green
    Current: 6A Voltage: 125V
    Screw: Steel Plastic: PA66
    Contact Resistance: Less Than 8mΩ Rated Surge Voltage: No Abnormal Within 1 Minute
    Inflammability Class: UL94, V-0 Contact Numbers: 2-24 Poles



    12 Poles Electronic Green pcb terminal block connector PA66 Pitch 2.54mm



    Detailed product Description:



    Pitch 2.54mm, 1250V 6A, 2P-24P, PCB Terminal blocks, PCB screw terminal blocks, Euro type Raising series



    ■ Right angle wire inlet

    ■ Double decks

    Standard color: Green.

    Other colors also available.



    Applications:



    1. PCB, Frequency Converters, Server Site, Switch, Power Supply

    2. Electric Lighting, Industry Control, Automation, Rail Transportation

    3. Communication, Electric Power, Security, Medicine Equipment, Military, Elevator, etc..



    Parameter and Drawing Specifications:

    UL Technical Data

    B

    C

    D

    Rated Voltage / Current              V/A

    125 / 6





    Wire Range                       AWG

    16-30





    IEC Technical Data



    Overvoltage Category

    Contamination Class

    3

    2

    2

    Rated Voltage / Current              V/A

    63 / 6

    160 / 6

    320 / 6

    Rated Surge Voltage                 KV

    1.5

    1.5

    1.5

    Rated Connecting Capacity           mm2

    0.5

    Material



    Insulation Material / Inflammability Class

    PA66 / UL94, V-0

    Clamp Cage / Plating

    Brass / Nickel Plated

    Terminal / Plating

    Brass / Tin Plated

    Screw / Plating

    Steel / Zinc Plated

    Other Data



    PCB Hole Diameter                 mm

    φ1.1

    Stripping Length                    mm

    4-5

    Screw / Torque                    / lbf.in

    M1.6 / 1.0-1.3



    Competitive Advantage:



    1. 10 main series and more than 1000 models for selection

    2. Stable good quality

    3. Flexible to design the exact part per customers' demand

    4. Resonable price

    5. Good servide.



    12 Poles Electronic Green pcb terminal block connector PA66 Pitch 2.54mm
