16mm2 Rated Feed-through Wire Connector for Current Demands and Heavy-Duty Applications

Product Description:

A Feed Through Terminal Block, also known as a through-wire terminal block, feed-through wire terminal, or through-type terminal connector, is an essential component in electrical and electronic applications for creating secure connections between wires. The Feed Through Terminal Block is designed to efficiently transmit electrical signals between different circuits or devices in a safe and reliable manner.

The Feed Through Terminal Block features a rated current of 30A, making it suitable for various low to medium power applications. This allows for the safe transmission of moderate levels of electricity without compromising the integrity of the connection.

With a connection type of screw, the Feed Through Terminal Block ensures a strong and secure attachment of wires to the terminal. The screw connection type provides stability and prevents accidental disconnection, offering peace of mind in demanding environments where vibrations or movements may occur.

The terminal width of 12.2mm provides ample space for wire connections, allowing for a comfortable and efficient wiring process. The generous terminal width accommodates different wire sizes and facilitates easy installation, saving time and effort during assembly.

When it comes to protection, the Feed Through Terminal Block offers the option of being equipped with or without a protector. The protector serves as an additional safety feature, safeguarding the terminal block and connected wires from external elements or potential damage. Users can choose the appropriate configuration based on their specific application requirements.

With a right-angle wire inlet, the Feed Through Terminal Block facilitates convenient wire insertion and routing. The right-angle design enables wires to enter the terminal block from the side, optimizing space utilization and allowing for neat and organized wire arrangements. This feature is particularly beneficial in applications where space constraints or cable management are crucial considerations.

Features:

• Product Name: Feed Through Terminal Block
• Material: Polyamide (PA)
• Protector: With Or Without Protector
• Clamp Cage: Brass
• Rated Current: 30A
• Screw: M5

Technical Parameters:

Applications:

The Feed Through Terminal Block by SCED is a versatile electrical connector designed for a wide range of applications. With its Through-type terminal connector design, this terminal block is ideal for scenarios where wires need to penetrate through the block for secure and reliable connections.

Originating from Jiangsu, Suzhou, this product boasts high quality and reliability, certified with CE and ISO9001 standards. The minimum order quantity for this terminal block is 500, making it suitable for both small and large-scale projects.

When it comes to installation, the Feed Through Terminal Block is easy to mount on DIN rails, making it a convenient choice for various industrial and commercial settings. The terminal block features a screw size of M5, ensuring a secure connection for wires. The terminal width of 12.2mm provides ample space for multiple wire connections.

The conduction board of this terminal block is made of copper, a material known for its excellent conductivity and durability. With a rated connecting capacity of 16mm2, this terminal block can accommodate a wide range of wire sizes, making it a versatile solution for different wiring needs.

For ordering convenience, customers can inquire about the latest price and packaging details for the Feed Through Terminal Block. The delivery time for this product is 30 days, and the payment terms accepted include T/T, AliPay, and PayPal. With a supply ability of 100,000pcs per day, customers can rely on a consistent and timely supply of this essential electrical component.

Customization:

Product Customization Services for the Feed Through Terminal Block:

Brand Name: SCED

Place of Origin: Jiangsu, Suzhou

Certification: CE, ISO9001

Minimum Order Quantity: 500

Price: Get latest price

Packaging Details: Carton box

Delivery Time: 30 day(s)

Payment Terms: T/T, AliPay, PayPal

Supply Ability: 100000pcs/day

Conduction Board: Copper

Rated Connecting Capacity: 16mm2

Torque: 14-16 Lbf.in

Protector: With Or Without Protector

Screw: M5

Support and Services:

Our Product Technical Support team for the Feed Through Terminal Block is dedicated to providing assistance with any technical issues or questions related to the product. Our team of experts can help troubleshoot problems, provide guidance on installation and usage, and offer solutions to optimize the performance of the terminal block.

In addition to technical support, we also offer a range of services to enhance the overall customer experience. These services may include product training, customization options, and maintenance plans to ensure the longevity and efficiency of the terminal block.

Packing and Shipping:

Product Packaging:

The Feed Through Terminal Block is carefully packaged to ensure safe delivery. Each terminal block is secured in a protective plastic cover and placed in a sturdy cardboard box to prevent any damage during transit.

Shipping:

Orders for the Feed Through Terminal Block are shipped within 1-2 business days of the order being placed. We use reliable shipping services to deliver the product to your location safely and efficiently. You will receive a tracking number to monitor the status of your shipment.

FAQ:

Q: What is the brand name of the Feed Through Terminal Block?

A: The brand name is SCED.

Q: Where is the Feed Through Terminal Block manufactured?

A: The product is manufactured in Jiangsu, Suzhou.

Q: What certifications does the Feed Through Terminal Block have?

A: The product is certified with CE and ISO9001.

Q: What is the minimum order quantity for the Feed Through Terminal Block?

A: The minimum order quantity is 500 units.

Q: What are the available payment terms for purchasing the Feed Through Terminal Block?

A: The available payment terms are T/T, AliPay, and PayPal.
