Strong and Secure Connections with Tin Plated Terminal Junction Blocks Rated at 150A

Strong and Secure Connections with Tin Plated Terminal Junction Blocks Rated at 150A

  • Highlight

    tin plated terminal junction blocks

    ,

    150A rated terminal blocks

    ,

    through panel terminal blocks

  • Number Of Poles
    2-24
  • Rated Voltage
    600V
  • Stripping Length
    26mm
  • Contact Plating
    Tin
  • Number Of Positions
    2 To 24
  • Poles
    1-24
  • Insulation Material
    PA66
  • Contact Resistance
    Less Than 8mΩ
  • Place of Origin
    Jiangsu, suzhou
  • Brand Name
    SCED
  • Certification
    CE, ISO9001
  • Minimum Order Quantity
    500
  • Price
    Get latest price
  • Packaging Details
    Carton box
  • Delivery Time
    30 day(s)
  • Payment Terms
    T/T, AliPay, PayPal
  • Supply Ability
    100000pcs/day

Strong and Secure Connections with Tin Plated Terminal Junction Blocks Rated at 150A

Product Description:

The Through Panel Terminal Blocks are a versatile solution for panel placement terminal blocks that provide secure connections in various applications. These panel connector blocks are designed to handle a rated voltage of 600V, ensuring reliable performance in demanding electrical environments.

With contact plating made of tin, these terminal blocks offer excellent conductivity and corrosion resistance, enhancing the longevity of the connections. The tin plating also facilitates easy soldering and termination, making installation and maintenance processes more efficient.

Ensuring safety and reliability, these Through Panel Terminal Blocks have insulation resistance above DC500V, measuring at 500MΩ. This high level of insulation resistance minimizes the risk of electrical faults and ensures stable operation even in challenging conditions, providing peace of mind to users.

Available in a vibrant green color, these terminal blocks offer easy identification and organization within electrical panels. The distinct color coding helps in quick and accurate wiring, reducing the risk of errors during installation or troubleshooting procedures.

Featuring a versatile design, these terminal blocks come in various configurations to suit different requirements. Whether you need a 2-pole setup for simpler applications or a 24-pole arrangement for more complex systems, these terminal blocks offer flexibility and scalability to accommodate diverse project needs.

Overall, the Through Panel Terminal Blocks combine robust construction, reliable performance, and user-friendly features to serve as essential components in electrical panels and control systems. With their high voltage rating, efficient contact plating, superior insulation resistance, color-coded design, and multiple pole options, these terminal blocks are the ideal choice for creating secure and efficient connections in a wide range of industrial and commercial applications.



Features:

  • Product Name: Through Panel Terminal Blocks
  • Insulation Material: PA66
  • Conduction Board: Copper
  • Insulation Resistance: Above DC500V, 500MΩ
  • Number Of Positions: 2 To 24
  • Number Of Poles: 2-24


Technical Parameters:

Conduction Board Copper
Color Green
Inflammability Class UL94 V0
Contact Plating Tin
Insulation Material PA66
Stripping Length 26mm
Poles 1-24
Rated Current 150A
Rated Voltage 600V
Number Of Poles 2-24


Applications:

The Through Panel Terminal Blocks offered by SCED are versatile products that can be used in a variety of application occasions and scenarios. These terminal blocks, originating from Jiangsu, Suzhou, are designed to meet the highest standards, holding certifications such as CE and ISO9001.

With a minimum order quantity of 500 units, customers can easily obtain these high-quality terminal blocks at competitive prices. The packaging details include carton boxes to ensure safe delivery of the products to your location.

Delivery time for the Through Panel Terminal Blocks is 30 days, and customers can choose from payment terms such as T/T, AliPay, and PayPal for convenience. With a supply ability of 100,000pcs per day, SCED ensures that there is no shortage of these essential components.

The Through Panel Terminal Blocks come in a distinctive green color, making them easily identifiable in your setup. Rated for a voltage of 600V, these terminal blocks offer reliable performance in various electrical applications.

One of the key features of these terminal blocks is the stripping length of 26mm, allowing for easy installation and connection. The contact plating with tin ensures good conductivity and durability over time.

Moreover, the insulation resistance of these terminal blocks is above DC500V, with a value of 500MΩ, providing safety and protection in electrical circuits.

Panel Placement Terminal Blocks are ideal for industrial, commercial, and residential applications where secure and efficient electrical connections are needed. Whether you are working on control panels, machinery, or power distribution systems, these terminal blocks offer a reliable solution.



Customization:

Product Customization Services for Through Panel Terminal Blocks:

Brand Name: SCED

Place of Origin: Jiangsu, Suzhou

Certification: CE, ISO9001

Minimum Order Quantity: 500

Price: Get latest price

Packaging Details: Carton box

Delivery Time: 30 day(s)

Payment Terms: T/T, AliPay, PayPal

Supply Ability: 100000pcs/day

Contact Plating: Tin

Pole: 2-24 Poles

Conduction Board: Copper

Stripping Length: 26mm

Rated Current: 150A

Keywords: Panel Mounting Terminal Blocks, Panel mounted terminal blocks, Through Mount Terminal Blocks



Support and Services:

Our Product Technical Support and Services for Through Panel Terminal Blocks include:

- Expert assistance with installation and configuration

- Troubleshooting guidance for any issues that may arise

- Product training and documentation for optimal use

- Warranty information and support for product defects



Packing and Shipping:

Product: Through Panel Terminal Blocks

Description: High-quality terminal blocks for easy and secure electrical connections.

Package Contents: 10 terminal blocks

Packaging: Each terminal block is individually wrapped in bubble wrap and placed in a sturdy cardboard box for protection.

Shipping: We ship the product using reliable courier services to ensure safe and timely delivery to your location.



FAQ:

Q: What is the brand name of the Through Panel Terminal Blocks product?

A: The brand name is SCED.

Q: Where is the Through Panel Terminal Blocks product manufactured?

A: The product is manufactured in Jiangsu, Suzhou.

Q: What certifications does the Through Panel Terminal Blocks product have?

A: The product is certified with CE and ISO9001.

Q: What is the minimum order quantity for the Through Panel Terminal Blocks product?

A: The minimum order quantity is 500 units.

Q: What are the accepted payment terms for purchasing the Through Panel Terminal Blocks product?

A: The accepted payment terms are T/T, AliPay, and PayPal.
