Green Color Male Pluggable Terminal Block With Right Angle 7.62mm 300V 18A

Green Color Male Pluggable Terminal Block With Right Angle 7.62mm 300V 18A

    • Green Color Male Pluggable Terminal Block With Right Angle 7.62mm 300V 18A
    • Green Color Male Pluggable Terminal Block With Right Angle 7.62mm 300V 18A
  • Green Color Male Pluggable Terminal Block With Right Angle 7.62mm 300V 18A

    Product Details:

    Place of Origin: Guangdong, China
    Brand Name: SCED
    Certification: CE,UL
    Model Number: TP508H-76V

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000 Piece/Pieces
    Price: USD 0.018-0.045 Per Pole
    Packaging Details: Standard Master Carton Dimension: 341 x 273 x 198mm; Standard Inner box dimension: 168 x 134 x 47mm.
    Delivery Time: 5-20 Working Days
    Payment Terms: T/T, L/C
    Supply Ability: 1000000 Pole/Poles per Month
    Contact Now
    Detailed Product Description
    Color: Green Voltage: 300V
    Pitch: 7.62mm Current: 18A
    Poles: 2-16 Poles Terminal: Brass
    Contact Resistance: Less Than 8mΩ Rated Surge Voltage: No Abnormal Within 1 Minute
    Inflammability Class: UL94, V-0 Insulation Resistance: Above DC500V, 500MΩ

    Male Pluggable Terminal Block Green Color Right Angle 7.62mm 300V 18A



    Detailed product Description:



    Header, Male Sockets, Pitch: 7.62mm, 300V 18A, 2-16P, Pluggable Terminal Blocks, Plug-in Terminal Blocks



    This male header match with female plugs’ series: TP508P-76, TP508P-77, TP508P-78, TP508P-79



    Wire Inlet: ■Right angle wire inlet

    Levels: ■Single Level



    Standard color: Green.

    Other colors also available, please refer to below How to Order and select the color you want.



    Applications:



    1. PCB, Frequency Converters, Server Site, Switch, Power Supply, Electric Lighting, Industry Control 2. Automation, Rail Transportation, Communication, Electric Power, Security, Medicine Equipment, Military and Elevator and so on.



    Competitive Advantage:



    1. Full range products for selection
    2. Flexible to design the exact part per customers’ demand
    3. High quality but competitive price

    Parameter and Drawing Specifications:

    UL Technical Data B C D
    Rated Voltage / Current V/A 300/18   300/18
    IEC Technical Data
    Overvoltage Category
    Contamination Class 3 2 2
    Rated Voltage / Current V/A 400 / 18 630 / 18 1000 / 18
    Rated Surge Voltage KV 6 6 6
    Material
    Insulation Material / Inflammability Class PA66 / UL94, V-0
    Terminal / Plating Brass / Tin Plated
    Other Data
    PCB Hole Diameter mm φ1.4
    Pin Dimension mm 1.0 x 1.0



    Green Color Male Pluggable Terminal Block With Right Angle 7.62mm 300V 18A
