| Current Rating: | 10A | Wire Gauge: | 22-14 AWG |
|---|---|---|---|
| Color: | Gray/Black | Type: | Terminal Block |
| Operating Temperature: | -25°C To +85°C | Material: | Plastic/Metal |
| Mounting Type: | Panel Mount | Pitch: | 5.0mm |
| High Light: | 24 Poles Pluggable Terminal Block,2 Poles Pluggable Terminal Block |
||
Pluggable terminal blocks are reliable and secure connections for wiring applications. These connectors offer a perfect solution for a wide range of applications that require secure and easy wiring. The terminal blocks are designed with a 5.0mm pitch and feature a wire gauge of 22-14 AWG. The Gray/Black Pluggable terminal blocks are designed to withstand up to 3000V AC/minute and have an insulation resistance of >1000MΩ. These Pluggable terminal blocks provide a reliable and secure connection for your wiring needs.
| Product Name | Pluggable Terminal Block |
|---|---|
| Type | Terminal Block |
| Poles | 2-24 |
| Material | Plastic/Metal |
| Color | Gray/Black |
| Termination Type | Screw |
| Mounting Type | Panel Mount |
| Current Rating | 10A |
| Insulation Resistance | >1000MΩ |
| Withstanding Voltage | 3000V AC/minute |
SCED Pluggable Terminal Block is a reliable and easy-to-use connector designed for a wide range of applications. With its UL and CE certified voltage rating of 250V, insulation resistance of >1000MΩ, screw termination type, and 5.0mm pitch, it is the perfect solution for industrial, automotive, military, and aerospace applications. Its operating temperature range of -25°C to +85°C makes it suitable for any environment. With its high-quality design, the SCED Pluggable Terminal Block provides secure and reliable connections for any application.
Our SCED Pluggable Terminal Block is designed to meet the highest standards. With a brand name from China, it is UL and CE certified, making it ideal for the most critical applications. It features a screw termination type, and is available in either gray or black. It supports wire gauges from 22-14 AWG, and can withstand operating temperatures from -25°C to +85°C. The insulation resistance is >1000MΩ, making it a reliable and secure connector.
Packaging: The Pluggable Terminal Block is packaged in a cardboard box. The box includes all of the necessary components for installation and use. Inside the box, the product is secured with bubble wrap, foam, and other protective materials.
Shipping: The Pluggable Terminal Block is shipped using a reliable courier service. The package is tracked to ensure it reaches its destination safely and on time. The customer can select their preferred shipping method at checkout.
