Electrical Barrier Terminal Block 600V 40A OEM / ODM For INVERTERS

    • Electrical Barrier Terminal Block 600V 40A OEM / ODM For INVERTERS
    • Electrical Barrier Terminal Block 600V 40A OEM / ODM For INVERTERS
  • Electrical Barrier Terminal Block 600V 40A OEM / ODM For INVERTERS

    Product Details:

    Place of Origin: Shenzhen, China
    Brand Name: SCED
    Certification: UL, CE
    Model Number: TB1300-00-C

    Payment & Shipping Terms:

    Minimum Order Quantity: 500
    Price: Get latest price
    Packaging Details: Standard Export Carton
    Delivery Time: 7-20 working days
    Payment Terms: T/T
    Supply Ability: 1KK poles each monthly
    Contact Now
    Detailed Product Description
    Material: PBT Brass Color: Black
    Screw: M4 Torque: 10.6-13 Ibf.in
    Voltage: 600V Current: 40A

    Electrical Barrier Terminal Block 600V 40A OEM / ODM For INVERTERS



    1. Single screw Level;

    2. Right angle wire inlet;

    3. Clamp cage and terminal is high quality brass or copper





    Parameter and Drawing Specifications:

    UL Technical Data

    B

    C

    D

    Rated Voltage / Current              V/A

    600 / 40

    600 / 40

    600 / 5

    Wire Range                       AWG

    20-8

    20-8

    20-8

    IEC Technical Data



    Overvoltage Category

    Contamination Class

    3

    2

    2

    Rated Voltage / Current              V/A

    800 / 40

    1000 / 40

    1000 / 40

    Rated Surge Voltage                 KV

    8

    8

    8

    Rated Connecting Capacity           mm2

    4

    Material



    Insulation Material / Inflammability Class

    PBT / UL94, V-0

    Terminal / Plating

    Brass /Tin Plated

    Screw / Plating

    Steel / Nickel Plated

    Other Data



    PCB Hole Diameter                  mm

    φ2.5

    Stripping Length                    mm

    10-11

    Screw / Torque                    / lbf.in

    M 4 / 10.6-13





    Standard color: Black. Other colors also available, please refer to below How to Order and select the color you want.

    How to order:





    Applications:



    1. PCB. INVERTERS

    2. Frequency Converters, Server Site, Switch,

    3.Power Supply, Electric Lighting, Industry Control, Automation, etc..



    Competitive Advantage:



    1. Stable good quality
    2. Competitive price
    3. Quickly response
    4. Full range products for selection
    5. Flexible to design the exact part per customers’ demand



    Electrical Barrier Terminal Block 600V 40A OEM / ODM For INVERTERS



    Photos and Drawing:






    Photo:



    Electrical Barrier Terminal Block 600V 40A OEM / ODM For INVERTERS
