Pitch 5.0mm PCB Terminal Blocks Connector , 2 Way / 3 Way Screw Clamp Blocks

Pitch 5.0mm PCB Terminal Blocks Connector , 2 Way / 3 Way Screw Clamp Blocks

  • Pitch 5.0mm PCB Terminal Blocks Connector , 2 Way / 3 Way Screw Clamp Blocks
Pitch 5.0mm PCB Terminal Blocks Connector , 2 Way / 3 Way Screw Clamp Blocks
Product Details:
Place of Origin: Shenzhen, China
Brand Name: SCED
Certification: UL, CE
Model Number: TJ500-03-T1
Payment & Shipping Terms:
Minimum Order Quantity: 500
Price: Get latest price
Packaging Details: Standard Export Carton
Delivery Time: 7-20 working days
Payment Terms: T/T
Supply Ability: 1KK poles each monthly
Contact Now
Detailed Product Description
Applications: PCB, Frequency Converters, Server Site, Switch, Power Supply, Electric Lighting, Industry Control Color: Green
Pitch: 5.0mm Rated Current: 10A
Rated Voltage: 300V
High Light:

pcb screw terminal blocks

,

pcb terminal block connectors





Pitch 5.0mm PCB Terminal Blocks Connector , 2 Way / 3 Way Screw Clamp Blocks





Type:

PCB Terminal blocks,   PCB screw terminal blocks,              Euro type Raising series

Pitch:

5.0mm

Rated Voltage:

300V

Rated Current:

10A

Standard Color:

Green, other color is available

Number Of Contacts:

2P-28P

Wire Range:

12-26AWG

Applications:

PCB, Frequency Converters, Server Site, Switch, Power Supply, Electric Lighting, Industry Control, Elevator, etc.

PCB screw terminal blocks, Pitch 5.0mm, 300V 10A, 2P-24P, PCB Terminal blocks , Euro type Raising series



UL Technical Data

B

C

D

Rated Voltage / Current              V/A

300/10



300/10

Wire Range                       AWG

12-26



12-26

IEC Technical Data



Overvoltage Category

Contamination Class

3

2

2

Rated Voltage / Current              V/A

250 / 10

400 / 10

630 / 10

Rated Surge Voltage                 KV

4

4

4

Rated Connecting Capacity           mm2

2.5

Material



Insulation Material / Inflammability Class

PA66 / UL94, V-0

Clamp Cage / Plating

Brass / Nickel Plated

Terminal / Plating

Brass / Tin Plated

Screw / Plating

Steel / Zinc Plated

Other Data



PCB Hole Diameter                  mm

φ1.5

Stripping Length                    mm

6-7

Screw / Torque                    / lbf.in

M3 / 4.4-5.3

Pitch 5.0mm PCB Terminal Blocks Connector , 2 Way / 3 Way Screw Clamp Blocks 0

Standard color: Green. Other colors also available, please refer to below How to Order and select the color you want.

How to order:

Pitch 5.0mm PCB Terminal Blocks Connector , 2 Way / 3 Way Screw Clamp Blocks 1

Competitive Advantage:



  1. Stable good quality
  2. Competitive price
  3. Quickly response
  4. Full range products for selection
  5. Flexible to design the exact part per customers' demand

Pitch 5.0mm PCB Terminal Blocks Connector , 2 Way / 3 Way Screw Clamp Blocks 2
