2 Pin Plug In Terminal Blocks Connector Male Sockets 3.81mm Pitch

2 Pin Plug In Terminal Blocks Connector Male Sockets 3.81mm Pitch

  • 2 Pin Plug In Terminal Blocks Connector Male Sockets 3.81mm Pitch
2 Pin Plug In Terminal Blocks Connector Male Sockets 3.81mm Pitch
Product Details:
Place of Origin: Shenzhen, China
Brand Name: SCED
Certification: UL, CE
Model Number: TP381H-01
Payment & Shipping Terms:
Minimum Order Quantity: 500
Price: Get latest price
Packaging Details: Standard Export Carton
Delivery Time: 7-20 working days
Payment Terms: T/T
Supply Ability: 1KK poles each monthly
Contact Now
Detailed Product Description
Applications: PCB, Frequency Converters, Server Site, Switch, Power Supply, Electric Lighting, Industry Control Color: Green
Number Of Contacts: 2*2P - 22*2P Pitch: 3.81mm
Rated Current: 8A Rated Voltage: 300V
Type: Plug In Terminal Blocks,Pluggable Terminal Blocks, Plug-in Terminal Blocks Wire Inlet: Vertical Wire Inlet
High Light:

power terminal block connector

,

electric terminal block

2 Pin Plug In Terminal Blocks Connector Male Sockets 3.81mm Pitch

□Right angle wire inlet;  ■Vertical wire inlet;  □45 degree wire inlet
□Single Level;  ■Double Levels;  □Triple Levels

This male socket match with female plug series: TP381P-00, TP381P-01, TP381P-02, TP381P-03, TP381P-04

Standard color: Green. Other colors also available, please refer to below How to Order and select the color

you want.
Pluggable Terminal Blocks, Plug-in Terminal Blocks, Terminal Block Connectors, PCB Connectors





How to order:
2 Pin Plug In Terminal Blocks Connector Male Sockets 3.81mm Pitch 0


Applications:

PCB, Frequency Converters, Server Site, Switch, Power Supply, Electric Lighting, Industry Control,
Automation, Rail Transportation, Communication, Electric Power, Security, Medicine Equipment, Military,
Elevator, etc..


Parameter and Drawing Specifications:



UL Technical Data

B

C

D

Rated Voltage / Current              V/A

300 / 8





Wire Range                       AWG







IEC Technical Data



Overvoltage Category

Contamination Class

3

2

2

Rated Voltage / Current              V/A

160 / 8

160 / 8

320 / 8

Rated Surge Voltage                 KV

2.5

2.5

2.5

Material



Insulation Material / Inflammability Class

PA66 / UL94, V-0

Terminal / Plating

Brass / Tin Plated

Other Data



PCB Hole Diameter               mm

φ1.2

PinDimension                     mm

0.8 x 0.8





2 Pin Plug In Terminal Blocks Connector Male Sockets 3.81mm Pitch 1


Competitive Advantage:



1. Stable good quality

2. Competitive price

3. Quickly response

4. Full range products for selection

5. Flexible to design the exact part per customers’ demand
